STRAINER - Y TYPE

  • Minimum quantity1 Pieces
  • Port of dispatchIndia
  • TypeTrader | Distributor | Wholesaler
  • Processing time10 Day
  • Estimate pricingNot-available
  • Packagingbag

Products Description

Fluid handled by industries contains various particles due to atmospheric contamination, in process contamination, during handling or transportation it may be contaminated. These particles are in varied sizes and shapes and may damage or harm the equipment such as heat exchangers, burners, chilling plants, carburetors, coolers, pumps, seals, valves etc. Also, some products may need final removal of particles to enhance value; to improve further process or to achieve required clarity. “ Y “ types of strainers are named after their shape and normally used for course filtration. But with large filtration area can be used with fine mesh also. “Y” strainers are available with 3 to 4 times larger filtration area than pipe size and suitable to install in either a horizontal or vertical position. Advanced dynamic flow path and large filtration area elements ensure low pressure drops and reduced maintenance periods. Strainers are available with wide range of sizes as well as filter varieties. Different types of perforate filter elements can be provided from 4 mesh to 500 mesh.

Products Specification

  • BODY & COVERASTM A 351 Gr. CF8 / CF8M / CF3 / CF3M / CN7M / ASTM A 216 GR. WCB / CAST IRON ( IS 210GR 220 )
  • SCREEN / FILTER ELEMENTAISI S.S 304 / S.S 316 / S.S 304 L / S.S 316 L
  • MESH SIZE4 MESH TO 500 MESH
  • Stud & NutASTM A 193 Gr. B7 /B8 / B8M
  • PACKINGS.S 304 / 316 Graphite Filler spiral Packing / P.T.F.E
  • End ConnectionFlanged End to ASME B-16.5, 150, 300 BS 10 Table D, E, F, H DIN / IS 6392
  • Flange StdASME B 16.5 RF Class 150 /300
  • Size RANGE1/2″ To 12″ ( 15 NB To 300 NB )
