12T Explosion Proof Battery Locomotive
- Estimate pricing$ 55645
- AvailabilityIn stock
- ModelCTYL12 /67, 9 B
- Adhesive / Total Weight12 t
- Track Gauge600,762, 900 mm
- Traction16.48 KN
Products Description
The 12T Explosion Proof Type IGBT Control Battery Locomotive has large traction, high speed, large loading capacity.Two sides of cabs has a wide sphere of vision. The 12T battery locomotive adopts IGBT contoller or frequency contoller. The shutoff ability of the main circuit of IGBT chopper is strong, the trigger circuit selects the integrated voltage source, integrated timer, composition elements, etc., which leads to less circuit components, easy installation and testing, easy and reliable in operation. IGBT control locomotive has simple electric circuits, stable starting,smooth speed regulation and easy maintenance,saving 30% of energy. Model No.CTYL12 /67, 9 B - 192 Adhesive / Total Weight (t)12 Track Gauge (mm)600,762, 900 Traction (KN)16.48 Max. Traction (KN)29.43 Speed(Km/h)8.7 Battery Voltage (V)192 Battery Capacity (Ah)560 Power (KW)22kw�2 DimensionsLength(mm)5100 Width(mm)1050/1212/1350 Height(mm)1600 Wheelbase (mm)1180 Wheel diameter (mm)680 Gearbox Height Over Rail(mm)�85 Coupler Height(mm)320mm/430mm Min Curve Radius (m)9 ControllerIGBT Control Drive Ratio17.5 Transmission MethodDual Level Gearing Braking methodElectric+Mechanical Brake
Product Categories
Products Specification
- ModelCTYL12 /67, 9 B
- Adhesive / Total Weight12 t
- Track Gauge600,762, 900 mm
- Traction16.48 KN
- Max. Traction29.43 KN
- Speed8.7 Km/h
- Battery Voltage192 V
- Battery Capacity560 Ah
- Power22kwÃ?2
- Length5100 mm
- Width1050/1212/1350 mm
- Height1600 mm
- Wheelbase1180 mm
- Wheel diameter680 mm
- Gearbox Height Over Rail≥85 mm
- Coupler Height320mm/430mm
- Min Curve Radius9 m
- ControllerIGBT Control
- Drive Ratio17.5
- Transmission MethodDual Level Gearing
- Braking methodElectric+Mechanical Brake
