Ssp Series

Falcon regenerative monoset pumpsets are powered by a totally enclosed fan cooled AC induction two pole motor. Motor stator is made of low watt loss silicon steel laminations assembled under pressure and rigidly locked in the frame. The windings are of high-grade enameled copper wire offer excellent resistance and are varnish impregnated. Construction of motor frame and usage of quality materials result in high performance and low temperature rise thereby increasing the life cycle of the motor. Salient Features High operating efficiency resulting in lower power consumption. - Good suction lift characteristics. - Specially designed for wide voltage operation. - Dynamically balanced rotating parts including rotor and impeller ensures minimum vibration and longer life. - Back pull-out design for easy servicing and repair. - Double shielded ball bearings, so no need of external lubrication. - All Model fitted to Mechanical seal. specification Power Range : 0.37 Kw - 0.75 Kw (0.5 HP - 1.0 HP) - Version : Single Phase, 220-240V, 50Hz AC Supply - Speed : 1440 RPM - Maximum Total Head : 18 Mtr. - Maximum Flow Rate : 4200 LPH - Maximum Suction Lift : 8 Mtr. - Degree of Protection : IP 44 - Class of Insulation : B0 - Maximum Ambient Tem. : 40 C - Sealing : Mechanical Seal - Type of Duty : S1 (Continuous) - Direction of Rotation : Single Phase, Clockwise from driving end - Nominal Pumpset Size (Suction X Delivery) : 25mm X 25mm Characteristics Of Clear Cold Water - Maximum liquid temperature : 33C max - Permissible amount of sand : 25 g/m - Allowable solids : 3000 ppm (max.) - Chloride ion density : 500 ppm (max.) - Turbidity : 50 ppm silica scale (max.) - Hardness (Drinking Water) : 300 ppm (max.) - Specific gravity : 1.004 (max.) 6 - Viscosity : 1.75 x 10 m/sec (max.) - Ph Value : 6.5 to 8.5 material Of construction - Motor Part Name Material Mechanical Seal : Carbon & Ceramic Motor Shaft : SS-410 Motor Body : FG-250 Bearing : SKF End Cover : FG-250 Bracket : FG-250 Flange : FG-250 Casing : FG-250 Impeller : Brass Cooling Fan : Plastic
