RS485 Cellular Gateway
- Estimate pricing$ 110
- AvailabilityIn stock
- DC power input10-30V @1A
- Cellular moduleSierra Wireless LTE CAT4
- USB interfaceMicro USB
- GNSS supportGPS, GLONASS, Galileo, BeiDou
Products Description
INTERFACES DC POWER INPUT 10-30V Wide DC input @1A (non-isolated) Accidental reverse voltage, ESD (IEC61000-4-2 level 4), EFT (IEC61000-4-4 level 2) and Surge (IEC61000-4-5 level 1) protected. Internal Overvoltage, Over current protection Internal circuitry to enable remote power ON/OFF of 12V rail. Connection by means of 2 piece pluggable screw terminal connector CELLULAR INTERFACE â?¢ Based on Sierra Wireless Module â?¢ LTE CAT4 cellular connectivity with UMTS/GPRS fallback Following key features of the Module o 4G LTE CAT4 : B1 / B3 / B5 / B8 / B40 / B41 o 3G UMTS/HSPA+: B1/ B8 o 2G EDGE/GSM/GPRS: 900/ 1800 MHz Interfaces o Two SMA connectors for External Main and Diversity Antennas o Single Nano SIM USB INTERFACE Micro USB interface for connecting Host. GPS Supports RF bands of GPS, GLONASS, Galileo, BeiDou â?¢ SMA connector for External Antenna (Main and Diversity) â?¢ Supports active or Passive GPS Antenna by assembly option â?¢ 3.7V at 20mA available for supporting active antenna RS-485 â?¢ 3KV isolated Half duplex RS-485 channel â?¢ ESD (IEC61000-4-2 level 4), EFT (IEC61000-4-4 level 2) and Surge (IEC61000-4-5 level 1) protected. Connection by means of screw terminal connectors EMMC FLASH 4GB eMMC flash for Internal Data storage
Product Categories
Products Specification
- DC power input10-30V @1A
- Cellular moduleSierra Wireless LTE CAT4
- USB interfaceMicro USB
- GNSS supportGPS, GLONASS, Galileo, BeiDou
- SIM typeNano SIM
- Antenna connectorsTwo SMA (Main and Diversity)
- RS-4853KV isolated half duplex
- Storage4GB eMMC flash
Inquire now
Related Products
More related Products from Seller
Post your requirement – Global Trade Plaza
Other Products from Seller
More RS485 Cellular Gateway from Category
![resources of Apple Watch Ultra 3 [GPS + Cellular 49mm] Running & Multisport Smartwatch w/Rugged Titanium Case w/Black exporters](https://img.globaltradeplaza.com/uploads/2026/7/17/9283/1784297308/apple-watch-ultra-3-gps-cellular-49mm-running-multisport-smartwatch-wrugged-titanium-case-wblack-exporter.png "resources of Apple Watch Ultra 3 [GPS + Cellular 49mm] Running & Multisport Smartwatch w/Rugged Titanium Case w/Black exporters")
RS485 Cellular Gateway from other sellers
![resources of Apple Watch Series 10 [GPS + Cellular 42mm] with Jet Black Aluminium Case with Black Sport Band - M/L. Fitness Tracker, ECG App, exporters](https://img.globaltradeplaza.com/uploads/2026/7/17/9283/1784298852/apple-watch-series-10-gps-cellular-42mm-with-jet-black-aluminium-case-with-black-sport-band-ml-fitness-tracker-ecg-app-exporter.png "resources of Apple Watch Series 10 [GPS + Cellular 42mm] with Jet Black Aluminium Case with Black Sport Band - M/L. Fitness Tracker, ECG App, exporters"){kind=tracking}
Buy Online Wholesale RS485 Cellular Gateway from Supplier & Exporter in India
The cellular interface is based on a Sierra Wireless LTE CAT4 module with UMTS/GPRS fallback, supporting specific bands (LTE CAT4: B1/B3/B5/B8/B40/B41; 3G UMTS/HSPA+: B1/B8; 2G EDGE/GSM/GPRS: 900/1800 MHz), two SMA connectors for external main and diversity antennas, and a single Nano SIM. It includes a Micro USB interface for host connection, GPS support for RF bands (GPS, GLONASS, Galileo, BeiDou) with optional active/passive antenna via SMA connector and 3.7V at 20mA for active antennas, an isolated 3KV half-duplex RS-485 channel with surge protection via screw terminal connectors, and 4GB eMMC flash for internal data storage.
