Ceramic Capacitor Voltage Multiplier Circuits

Ceramic capacitor multistage stacks component for spraying gun PRODUCT DESCRIPTION Voltage doubler module (high voltage stack capacitor) is an integrated voltage doubler integrated rectifier module, which is part of the entire circuit integrated in a device, because of its integrated structure, so it is not subject to vibration, humidity, gas corrosion, not afraid of dust, oil Baptist, can work in harsh environments. Ideal for use in photomultipliers, ionization chambers and similar stable high voltage DC rectifiers that require high voltage, low leakage detection devices. Low dissipation, small tolerance Good charge and discharge performance Small size, high withstand voltage A variety of series, a variety of assembly way Stable electrostatic capacity ELECTRICAL PARAMETER Name: multiplier ceramic high voltage capacitor Frequency:1KHz The rated voltage:10 ~ 50 KV Insulation resistance:(IR)�10000MΩ The loss tangent:Tg �0.3% Capacitance:10 ~103 PF Tolerance:K (± 10%) Withstand voltage test:DC1.5 times no breakdown or flashover SPECIFICATION TABLE A-Model parameter table Series A: enhanced, by silver fittings connection between capacitance per level, str ucture optimization, heat evenly, increase insulation, good reliability Material code Capacity Rated voltage D (mm) L (mm) PCS/STACK CDM20KV151KB12 150PF 20KV 6.1 71 12 CDM10KV251KB12 250PF 10KV 5.2 66 12 CDM20KV331KB11 330PF 20KV 7.8 66 12 CDM20KV471KB12 470PF 20KV 8.3 75 12 CDM20KV501KB12 500PF 20KV 8.3 74 12 CDM30KV221KB10 220PF 30KV 8.5 91 10 Can provide module customization, multi-level customization is ok B-Model parameter table B series: economy, direct welding between capacitance per level, and unilateral or bilateral derivation leads to two kinds of structure, cheap, economical and practica l, overall length can be adjusted according to customer's requirements. Material code Capacity Rated voltage D (mm) L (mm) PCS/STACK CDM20KV101KA10 100PF 20KV 5.2 62 10 CDM20KV151KA12 150PF 20KV 6.2 60 12 CDM20KV251KA12 250PF 20KV 5.2 59 12 CDM20KV301KA12 300PF 20KV 8.0 60 12 CDM20KV351KA12 350PF 20KV 6.2 58 12 CDM20KV471KA12 470PF 20KV 8.7 63 12 Can provide module customization, multi-level customization is welcome APPLICATION FIELD Suitable for electrostatic spraying doubler module circuit application and typical handheld high-voltage electrostatic spray gun, the built-in high voltage module, low and high pressure anion generator in high voltage power supply components. Static electricity generating circuit, spraying machines, electrostatic flocking equipment, doubler circuit, high frequency doubler rectifier circuit, a major part of the multistage doubler rectifier circuit, low power dc high voltage power supply, etc
